Ventilator N24, 3-fase

Ventilator N24, 3-fase

Een centrifugaal ventilator bedoeld voor gebruik met Nederman afzuigapparatuur.

  • Compact
  • Gebruiksvriendelijk

Technische gegevens
Certificeringen CE
Geluidsniveau (db(A)) 61 dB(A) bij 1200 m³ per uur
Installatie Binnen, Buiten
Luchtstroom (m³/per uur) 1500
Omgevingstemperatuur -20 to +40 C (-4 F to 104 F)
Operating Temperature Max 60 C
Frequentie (Hz) 50
Aantal fase 3
Gewicht (kg) 17
Vermogen (kW) 0,9

Modellen3

Toebehoren bij dit product 32

PVC hose. Ø100mm. l=5m
ArtNo: 10500427

Pvc-hose. diam.100mm.L=5m

PVC-hose. Ø125mm. l=5m.
ArtNo: 10500527

Pvc-hose. diam.5". l=5m.

PVC-hose. Ø150mm. l=5m.
ArtNo: 10500627

Pvc-hose. diam.6". l=5m.

PVC-hose Ø 160mm. l=5m
ArtNo: 10511026

Pvc-hose diam. 160mm.L=5m

Inlet and outlet adaptor for hose Ø160 mm
ArtNo: 14322166

In- and outlet connection with

Guard net (1 pcs)
ArtNo: 14333181

Guard net for fan N16 and N24.

Adaptor Ø125/Ø100 mm
ArtNo: 14341077

Reducer. diam.125/100mm.

Adaptor Ø125/Ø75 mm
ArtNo: 14341080

Reducer. diam.125/75mm. black.

Wall bracket for silencer
ArtNo: 14343089

Wall bracket for silencer. pair.

Nozzle with magnet. 250 x 30 mm. Aluminium. Hose connection Ø100 mm.
ArtNo: 14500226

Nozzle. silumin. with magnet.

Split inlet Ø125 int. / 2xØ125 mm ext.
ArtNo: 14500726

Double adapter. diam.125mm/2x125mm.

Split inlet Ø125 int. / 2xØ75 mm ext.
ArtNo: 14500826

Double adapter. diam.125mm/2x75mm.

Nozzle with magnet. 260 x 100 mm. Polycarbonate. Hose connection Ø100 mm.
ArtNo: 14501226

Nozzle. plastic. with magnet.

Silencer for when when mounted on Original or Telescopic extraction arm
ArtNo: 14502126

Exhaust silencer for fan.

Silencer including quick release
ArtNo: 14502226

Silencer.Including quick release

FMS 1,6-2,5, ventilatorstarter inclusief thermische motorbeveiliging 1,6 - 2,5A
ArtNo: 14502237

FMS 1,6-2,5, ventilatorstarter inclusief thermische motorbeveiliging 1,6 - 2,5A

Silencer for fan
ArtNo: 14502626

Silencer for fan

Coupling tube Ø75mm
ArtNo: 14503626

Connector 3"-3". (75mm).

Coupling tube Ø100mm
ArtNo: 14504626

Connector 4"-4". (100mm).

Coupling tube Ø125mm
ArtNo: 14505626

Connector 5"-5". (125mm).

Coupling tube Ø150mm
ArtNo: 14506626

Connector 6"-6". (150mm).

Stand for fans N10, N16 and N24
ArtNo: 14510126

Support bracket for N10/N16/N24 for fixed mounting. Incl guard net and inlet connection.

Inlet adaptor for hose Ø160 mm
ArtNo: 14510326

Adapter diam.=160mm.

Adaptor Ø160/ext. Ø75 mm
ArtNo: 14510426

Reducer inside diam=160mm. outside

Adaptor Ø160/ext. Ø100 mm
ArtNo: 14510526

Reducer inside diam=160mm. outside

Adaptor Ø160 ext./Ø125 mm
ArtNo: 14510626

Reducer inside diam=160mm. outside

Split inlet Ø160 int. / 2xØ100 mm ext.
ArtNo: 14510726

Split intake(t-tube).

Adaptor Ø160/Ø150 mm
ArtNo: 14511226

Adapter. diam 160/150mm.

Coupling tube Ø160mm
ArtNo: 14511326

Adapter diam=160mm

Support bracket for portable N16 and N24 fan
ArtNo: 14511426

Bracket for serial N16 and N24 portable

Handbediende ventilatorregeling, 1 - 5A, 3 fase
ArtNo: 14518637

Handbediende ventilatorregeling, 1 - 5A, 3 fase

Automatische ventilatorregeling, 1 - 5A, 3 fase
ArtNo: 14519037

Automatische ventilatorregeling, 1 - 5A, 3 fase
