Nederman

Fan N40

Fan N40

A centrifugal fan mainly designed for use with Nederman extraction products.


Note! The fan must not be used in an environment with danger of explosion or for transport of inflammable or explosive gases.

  • Compact
  • Easy to use

Technical data
Certifications CE
Noise level (dB(A)) 70 at 2500 m3/h
Installation Indoor, Outdoor
Airflow (m³/h) 2500 (1,5 kW), 4000 (2,2 kW)
Ambient temperature range -20 to +40 C (-4 F to 104 F)
Operating Temperature Max. 60 C
No of phases 3

Models5

    N40 fan 2.2kw.230/460v.3-phase.

    ArtNo: 14510223

    Amperage (A)
    7,3/3,6
    Cord length (m)
    2
    Frequency (Hz)
    60
    Power (kW)
    2,2
    Power Voltage (V)
    230/460
    Weight (kg)
    30
    N40 fan 2.2kw.200-240/380-420v.

    ArtNo: 14510123

    Power Voltage (V)
    230/400
    Frequency (Hz)
    50
    Amperage (A)
    8/4,6
    Weight (kg)
    29
    Power (kW)
    2,2
    N40 fan 1.5kw. 200-240/380-420v.

    ArtNo: 14510623

    Power Voltage (V)
    230/400
    Frequency (Hz)
    50
    Amperage (A)
    5,5/3,2
    Weight (kg)
    25
    Power (kW)
    1,5
    Fan N40 575V 3hp 3ph 60Hz

    ArtNo: 14511723

    Amperage (A)
    3,2
    Frequency (Hz)
    60
    Power (kW)
    2,2
    Power Voltage (V)
    575
    Weight (kg)
    30
    N40 2,2kW 380V/60Hz/3ph

    ArtNo: 14523121

    Power Voltage (V)
    380
    Frequency (Hz)
    60
    Amperage (A)
    4,5
    Weight (kg)
    29
    Power (kW)
    2,2

Accessories for this product 4

FMS 2.5-4 Fan Manual Starter incl. motor protector 2.5-4A
ArtNo: 14502337

FMS 2.5-4 Fan Manual Starter

FMS 4-6.3 Fan Manual Starter incl. Motorprotector 4-6.3A
ArtNo: 14502437

FMS 4-6.3 Fan Manual Starter

Bracket for fan n40
ArtNo: 14510226

Bracket for fan n40

Manual fan control. 3,2 - 11,5 A, 3 phase.
ArtNo: 14518737

Caixa de controlo manual FCM 3,2 - 11,5A, 3 fases
