NCF fans 60Hz

NCF fans 60Hz

The Nederman NCF Fans have direct drive motors which means a safe and cost effective operation. Installing an energy efficient NCF fan with our other Nederman products saves time and reduces energy costs. It is a centrifugal fan designed for use in all types of industrial process and ventilation systems, mounted indoor as well as outdoor. The fan is equipped with vibration absorbers as standard.

Technical data
Certifications CE
Protection class IP 55
Installation Outdoor, Indoor
Material Sheet metal, painted grey, RAL 7045
Ambient temperature range -30 to +40 °C (22 F to 104 F)
Operating Temperature Max 140 F (60 C)
Frequency (Hz) 60
No of phases 3

Models24

    FAN NCF 30/15

    ArtNo: 14521828

    Amperage (A)
    8,6
    Noise level (dB(A))
    69 db(A) at 2500 m³/h
    Power (Hp)
    3.0 (2.2 Kw)
    Power Voltage (V)
    208
    Weight (lbs)
    148
    FAN NCF 30/20

    ArtNo: 14521928

    Amperage (A)
    11,5
    Power (Hp)
    4.0 (3 Kw)
    Power Voltage (V)
    208
    Weight (lbs)
    187
    FAN NCF 30/25

    ArtNo: 14522028

    Amperage (A)
    15,1
    Noise level (dB(A))
    74 db(A) at 4000 m³/h
    Power (Hp)
    5.4 (4 Kw)
    Power Voltage (V)
    208
    Weight (lbs)
    231
    FAN NCF 40/25

    ArtNo: 14522128

    Amperage (A)
    18,7
    Noise level (dB(A))
    75 db(A) at 4000 m³/h
    Power (Hp)
    7.4 (5.5 Kw)
    Power Voltage (V)
    208
    Weight (lbs)
    243
    FAN NCF 80/20

    ArtNo: 14522328

    Amperage (A)
    26,2
    Noise level (dB(A))
    77 db(A) at 6000 m³/h
    Power (Hp)
    10.0 (7.5 Kw)
    Power Voltage (V)
    207
    Weight (lbs)
    331
    Fan NCF 120/15

    ArtNo: 14522428

    Amperage (A)
    38,4
    Noise level (dB(A))
    85 db(A) at 10000 m³/h
    Power (Hp)
    14.7 (11 Kw)
    Power Voltage (V)
    208
    Weight (lbs)
    355
    FAN NCF 30/15

    ArtNo: 14522728

    Amperage (A)
    7,8/3,9
    Noise level (dB(A))
    69 db(A) at 2500 m³/h
    Power (Hp)
    3.0 (2.2 Kw)
    Power Voltage (V)
    230/460
    Weight (lbs)
    148
    FAN NCF 30/20

    ArtNo: 14522828

    Amperage (A)
    10,4/5,2
    Power (Hp)
    4.0 (3 Kw)
    Power Voltage (V)
    230/460
    Weight (lbs)
    187
    FAN NCF 30/25

    ArtNo: 14522928

    Amperage (A)
    13,6/6,8
    Noise level (dB(A))
    74 db(A) at 4000 m³/h
    Power (Hp)
    5.4 (4 Kw)
    Power Voltage (V)
    230/460
    Weight (lbs)
    231
    FAN NCF 40/25

    ArtNo: 14523028

    Power Voltage (V)
    230/460
    Amperage (A)
    17,0/8,5
    Noise level (dB(A))
    75 db(A) at 4000 m³/h
    Weight (lbs)
    243
    Power (Hp)
    7.4 (5.5 Kw)
    FAN NCF 50/25

    ArtNo: 14523128

    Amperage (A)
    17,0/8,5
    Noise level (dB(A))
    78 db(A) at 3500 m³/h
    Power (Hp)
    7.4 (5.5 Kw)
    Power Voltage (V)
    230/460
    Weight (lbs)
    247
    FAN NCF 80/20

    ArtNo: 14523228

    Amperage (A)
    23,8
    Noise level (dB(A))
    77 db(A) at 6000 m³/h
    Power (Hp)
    10.0 (7.5 Kw)
    Power Voltage (V)
    230/460
    Weight (lbs)
    331
    Fan NCF 120/15

    ArtNo: 14523328

    Amperage (A)
    34,8
    Noise level (dB(A))
    85 db(A) at 10000 m³/h
    Power (Hp)
    14.7 (11 Kw)
    Power Voltage (V)
    230/460
    Weight (lbs)
    355
    Fan NCF 120/25

    ArtNo: 14523428

    Power Voltage (V)
    230/460
    Amperage (A)
    46,8/23,4
    Noise level (dB(A))
    82 db(A) at 8000 m³/h
    Weight (lbs)
    511
    Power (Hp)
    20.0 (15 Kw)
    FAN NCF 160/25

    ArtNo: 14523528

    Power Voltage (V)
    230/460
    Amperage (A)
    60,0/30,0
    Noise level (dB(A))
    84 db(A) at 10000 m³/h
    Weight (lbs)
    644
    Power (Hp)
    24.8 (18.5 Kw)
    FAN NCF 30/15

    ArtNo: 14523628

    Power Voltage (V)
    575
    Amperage (A)
    3,1
    Noise level (dB(A))
    69 db(A) at 2500 m³/h
    Weight (lbs)
    148
    Power (Hp)
    3.0 (2.2 Kw)
    FAN NCF 30/20

    ArtNo: 14523728

    Amperage (A)
    4,2
    Power (Hp)
    4.0 (3 Kw)
    Power Voltage (V)
    575
    Weight (lbs)
    187
    FAN NCF 30/25

    ArtNo: 14523828

    Amperage (A)
    5,5
    Noise level (dB(A))
    74 db(A) at 4000 m³/h
    Power (Hp)
    5.4 (4 Kw)
    Power Voltage (V)
    575
    Weight (lbs)
    231
    FAN NCF 40/25

    ArtNo: 14523928

    Amperage (A)
    6,8
    Noise level (dB(A))
    75 db(A) at 4000 m³/h
    Power (Hp)
    7.4 (5.5 Kw)
    Power Voltage (V)
    575
    Weight (lbs)
    243
    FAN NCF 50/25

    ArtNo: 14524028

    Amperage (A)
    6,8
    Noise level (dB(A))
    78 db(A) at 3500 m³/h
    Power (Hp)
    7.4 (5.5 Kw)
    Power Voltage (V)
    575
    Weight (lbs)
    247
    FAN NCF 80/20

    ArtNo: 14524128

    Amperage (A)
    9,5
    Noise level (dB(A))
    77 db(A) at 6000 m³/h
    Power (Hp)
    10.0 (7.5 Kw)
    Power Voltage (V)
    575
    Weight (lbs)
    331
    FAN NCF 120/15

    ArtNo: 14524228

    Amperage (A)
    15
    Noise level (dB(A))
    85 db(A) at 10000 m³/h
    Power (Hp)
    15.0 (11 Kw)
    Power Voltage (V)
    575
    Weight (lbs)
    355
    Fan NCF 120/25

    ArtNo: 14524328

    Amperage (A)
    19,4
    Noise level (dB(A))
    82 db(A) at 8000 m³/h
    Power (Hp)
    20.0 (15 Kw)
    Power Voltage (V)
    575
    Weight (lbs)
    511
    FAN NCF 160/25

    ArtNo: 14524428

    Amperage (A)
    24,0
    Noise level (dB(A))
    84 db(A) at 10000 m³/h
    Power (Hp)
    24.8 (18.5 Kw)
    Power Voltage (V)
    575
    Weight (lbs)
    644

Accessories for this product 31

Inlet adap. D250 (10 in),30/15,40/25,50/25
ArtNo: 14374438

Inlet adap. D250 (10 in),30/15,40/25,50/25

Inlet adapter d315 (12 in), 30/25
ArtNo: 14374439

Inlet adapter d315 (12 in), 30/25

Inlet adapter d400 (16 in), 80/20, 120/25
ArtNo: 14374440

Inlet adapter d400 (16 in), 80/20, 120/25

Inlet adapter d500 (20 in), 120/15, 160/25
ArtNo: 14374441

Inlet adapter d500 (20 in), 120/15, 160/25

Outl. adap.288 (11.3") x205 (8 in) d315 (12 in),30/15,40/25
ArtNo: 14374442

Outl. adap.288 (11.3") x205 (8 in) d315 (12 in),30/15,40/25

Outlet adapter 322 (12.6 in)x229 (9 in) d400 (16 in), 30/25
ArtNo: 14374443

Outlet adapter 322 (12.6 in)x229 (9 in) d400 (16 in), 30/25

Outl.adap.361 (14.2 in) x256 (10 in) d400 (16 in),80/20,120/25
ArtNo: 14374444

Outl.adap.361 (14.2 in) x256 (10 in) d400 (16 in),80/20,120/25

Outl.adap.453 (17.8 in) x322 (12.6 in) d500 (20 in),120/15,160/25
ArtNo: 14374445

Outl.adap.453 (17.8 in) x322 (12.6 in) d500 (20 in),120/15,160/25

Outl.adap.256 (10 in) x183 (7.2 in) d250 (10 in), 50/25,30/20
ArtNo: 14374446

Outl.adap.256 (10 in) x183 (7.2 in) d250 (10 in), 50/25,30/20

Flex.inl.ad..d250 (10 in),30/15,40/25,50/25
ArtNo: 14374447

Flex.inl.ad..d250 (10 in),30/15,40/25,50/25

Flexible inlet adapter d315 (12 in), 30/25
ArtNo: 14374448

Flexible inlet adapter d315 (12 in), 30/25

Flex.inlet.adap.d400 (16 in), 80/20, 120/25
ArtNo: 14374449

Flex.inlet.adap.d400 (16 in), 80/20, 120/25

Flex.inlet.adap.d500 (20 in),120/15,160/25
ArtNo: 14374450

Flex.inlet.adap.d500 (20 in),120/15,160/25

Flex.out.a.288 (11.3 in) x205 (8 in) d315 (12 in),30/15,40/25
ArtNo: 14374451

Flex.out.a.288 (11.3 in) x205 (8 in) d315 (12 in),30/15,40/25

Flex.outlet adap.322 (12.6 in) x229 (9 in) d400 (16 in),30/25
ArtNo: 14374452

Flex.outlet adap.322 (12.6 in) x229 (9 in) d400 (16 in),30/25

Flex.out.a.361 (14.2 in) x256 (10 in) d400 (16 in),80/20,120/25
ArtNo: 14374453

Flex.out.a.361 (14.2 in) x256 (10 in) d400 (16 in),80/20,120/25

Flex.ou.a.453 (17.8 in) x322 (12.6 in) d500 (20 in),120/15,160/25
ArtNo: 14374454

Flex.ou.a.453 (17.8 in) x322 (12.6 in) d500 (20 in),120/15,160/25

Flex.ou.a.256 (10 in) x183 (7.2 in) d250 (10 in), 50/25,30/20
ArtNo: 14374455

Flex.ou.a.256 (10 in) x183 (7.2 in) d250 (10 in), 50/25,30/20

Inl.guardnet d250,30/15,40/25,50/25
ArtNo: 14374456

Inl.guardnet d250,30/15,40/25,50/25

Inlet guard net d315 (12 in), 30/25
ArtNo: 14374457

Inlet guard net d315 (12 in), 30/25

Inlet guard net d400 (16 in), 80/20, 120/25
ArtNo: 14374458

Inlet guard net d400 (16 in), 80/20, 120/25

Inlet guard net d500 (20 in),120/15,160/25
ArtNo: 14374459

Inlet guard net d500 (20 in),120/15,160/25

Outlet guard net, 30/15, 40/25
ArtNo: 14374460

Outlet guard net, 30/15, 40/25

Outlet guard net, 30/25
ArtNo: 14374461

Outlet guard net, 30/25

Outlet guard net, 80/20, 120/25
ArtNo: 14374462

Outlet guard net, 80/20, 120/25

Outlet guard net, 120/15, 160/25
ArtNo: 14374463

Outlet guard net, 120/15, 160/25

Outlet guard net, 50/25
ArtNo: 14374464

Outlet guard net, 50/25

Vibration absorber AM 30, 1 set
ArtNo: 14374628

Vibration absorber AM 30, 1 set

Vibration absorber AM 25, 1 set
ArtNo: 14374629

Vibration absorber AM 25, 1 set

Vibration absorber AM 50, 1 set
ArtNo: 14374630

Vibration absorber AM 50, 1 set

Inlet adapter d250 (10 in), 30/20
ArtNo: 14375076

Inlet adapter d250 (10 in), 30/20
